When you’re feeding your need for speed, Mercury Pro XS engines will get you there faster. Engineered to meet the demands for high speeds on fresh or salt water, these high-performance motors deliver a winning combination of power, acceleration, durability, and fuel efficiency.
| Built to take you almost anywhere and nearly 20 pounds lighter than its closest competitor, it's an incredibly fast high-output 150hp FourStroke outboard. | Great for bass, offshore fishing, and runabout boats. |
| HP / kW | 150 / 110 |
| Engine type | 8-valve single overhead cam (SOHC) Inline 4 |
| Displacement (CID/CC) | 183 |
| Displacement (L) | 3.0 |
| Full throttle RPM | 5200-6000 |
| Air induction | Performance-Tuned Scroll Intake Manifold |
| Fuel induction system | Computer Controlled Multi-Port Electronic Fuel Injection (EFI) |
| Recommended fuel | Unleaded Regular 87 Octane Minimum (R+M/2) or 90 RON 10% Ethanol Maximum |
| Recommended oil | NMMA Certified FCW SAE 10W-30 |
| Engine protection operator warning system | SmartCraft Engine Guardian |
| Compatible with SmartCraft digital technology | Yes |
| Starting | Electric (turn-key) |
| Controls | Mechanical throttle & shift |
| Steering | Dual cable mechanical/ Hydraulic power steering |
| Shaft length | 20" / 508 mm 25" / 635 mm |
| Gearcase ratio | 2.08:1 |
| Dry weight *Lightest model available | 456/207 |
| CARB star rating | 3 |
| Bore and stroke | 4.0" x 3.6" / 102mm x 92mm |
| Ignition | SmartCraft ECM 07 Digital Inductive |
| Cooling system | Water-cooled with thermostat |
| Gear shift | F-N-R |
| Trim system | Power Tilt/ Power Trim |
| Exhaust system | Through prop |
| Oil Capacity | 6.3 qts / 6.0L |
| Ideal for a wide range of fresh and saltwater boats. | Great for compact bass, multi-species, flats and bay boats, and pontoons. |
| HP / kW | 115 / 86 |
| Engine type | 8-valve single overhead cam (SOHC) Inline 4 |
| Displacement (L) | 2.1 |
| Full throttle RPM | 5300-6300 |
| Air induction | Performance-Tuned Scroll Intake Manifold |
| Fuel induction system | Computer Controlled Multi-Port Electronic Fuel Injection (EFI) |
| Alternator amp / Watt | 35 amp / 441 watt with water-cooled voltage regulator |
| Recommended fuel | Unleaded Regular 87 Octane Minimum (R+M/2) or 90 RON 10% Ethanol Maximum |
| Recommended oil | NMMA Certified FCW SAE 10W-30 |
| Engine protection operator warning system | SmartCraft Engine Guardian |
| Compatible with SmartCraft digital technology | Yes |
| Starting | Electric (turn-key)/ Smart Start Electric |
| Controls | Mechanical throttle & shift |
| Steering | Big Tiller Compatible/ Dual cable mechanical/ Hydraulic power steering |
| Shaft length | 20" / 508 mm 25" / 635 mm |
| Gearcase ratio | 2.07:1 |
| Dry weight *Lightest model available | 359 lbs / 163 kg |
| Bore and stroke | 3.5 x 3.2 /90 x 81 |
| Ignition | SmartCraft ECM 07 Digital Inductive |
| Fuel system | Electronic Fuel Injection (EFI) |
| Cooling system | Water-cooled with thermostat |
| Gear shift | F-N-R |
| Gearcase options | Standard |
| Trim system | Power Tilt/ Power Trim |
| Exhaust system | Through prop |
| Color | Phantom Black |
| Lubrication system | Wet sump |
| Oil Capacity | 5.5 qts / 5.2 l |
| Maximum Trim Range | 22° (-6° to 16°) |
| Maximum Tilt Range | 70° (-6° to 64°) |
