Smooth and Powerful
This Mercury Diesel engine sets a new benchmark for low noise and vibration.
With the motor racing season slowing down for the holiday period, Aussie racing legend Russell Ingall is looking forward to spending some quality time in his newly renovated Riviera M400.
Powered by a pair of Mercury Diesel TDI 370hp engines with Bravo 3 drives, and controlled via Mercury’s Joystick Piloting system, the boat has been a special project for Russell who’s particularly proud of the outcome.
DI technology uses injectors to spray diesel fuel atomized at 26,000 psi directly into the main combustion chamber of each cylinder. This process optimizes fuel efficiency and minimizes emissions, along with engine Noise, Vibration and Harshness (NVH) for an enjoyable boating experience.
The TDI engine block is fabricated from Vermicular Graphite Casting (VGC), which has twice the strength of grey iron and most of its attributes, but is 5% to 10% lighter. The end result is low weight, high strength, and maximum heat transfer for optimum cooling.
The only joystick piloting system that’s compatible with gasoline or diesel inboard and tow sport engines.
The only joystick piloting system for single-inboard boats.
The low weight of these diesels results in best-in-class power-to-weight ratio. Combined with great low-end torque, the end result is crowd-pleasing hole shot, great acceleration, low planing times and ultra-smooth performance.
Mercury® SmartCraft® compatibility is built into these engines, delivering key information about vital engine functions on an easy-to-read LED display. SmartCraft Digital Throttle & Shift (DTS) offers smooth shifting, immediate throttle response and high-tech digital controls.
Mercury diesels feature state-of-the-art anti-corrosion, including a thermostatically controlled closed water-cooled system. Water-cooled engine oil, gear oil and steering fluid decrease engine-room temperatures, extending engine life. The SeaCore® system is available for the ultimate in saltwater protection.
| Power mhp / kW | 370 / 272 |
| Bore and stroke | 3.27 x 3.74" / 83 x 95 mm |
| Maximum RPM (WOT) | 4200 |
| Engine type | V-8 |
| Displacement (L) | 4.2 |
| Weight (engine only) | 836 lbs / 379 kg |
| Weight (incl. transmission) | 933 lbs / 423 kg |
| Weight - Bravo One | 1067 lbs / 484 kg |
| Weight - Bravo Two | 1082 lbs / 491 kg |
| Weight - Bravo Three | 1093 lbs / 496 kg |
| Dimensions (L x W x H) | 47 x 33 x 33" / 1206 x 835 x 836 mm |
| Cooling system | Closed cooling |
| Fuel consumption | 20.5 gph / 77.6 lph @ 4200 |
| Compatible drives | Bravo One Bravo Three Bravo Two |
| Emission | BSO 2 RCD 2 IMO 2 EPA Tier 3 |
| Power mhp / kW | 335 / 246 |
| Bore and stroke | 3.27 x 3.74" / 83 x 95 mm |
| Maximum RPM (WOT) | 4200 |
| Engine type | V-8 |
| Displacement (L) | 4.2 |
| Weight (engine only) | 836 lbs / 379 kg |
| Weight (incl. transmission) | 933 lbs / 423 kg |
| Weight - Bravo One | 1067 lbs / 484 kg |
| Weight - Bravo Two | 1082 lbs / 491 kg |
| Weight - Bravo Three | 1093 lbs / 496 kg |
| Dimensions (L x W x H) | 47 x 33 x 33" / 1206 x 835 x 836 mm |
| Cooling system | Closed cooling |
| Fuel consumption | 18.5 gph / 69.9 lph @ 4200 rpm |
| Compatible drives | Bravo One Bravo Three Bravo Two |
| Emission | BSO 2 RCD 2 IMO 2 EPA Tier 3 |
